OPC-3301i
Specifications Manual
3
Item Specification Note
Brightness of white space 30 cd/m
2
or more
On LCD screen
Contrast ratio 100:1 or more
Main battery Lithium-ion 1100 mAh (typ.)
Charge the battery
before initial use
Up-time 48 hours or more
*1
Operating (charging) voltage 5.0 ~ 6.5V
Power Section
Current
consumption
Charging Less than 1 A
Charging with charger
Operating 0 ~ 50°C
Temperature
Storage -20 ~ 60°C
Operating 20 ~ 85%
Humidity
Storage 20 ~ 85%
No condensing
No frost
Fluorescent 10,000 lx or less
Ambient light
immunity
Sunlight 100,000 lx or less
Vibration
10 Hz ~ 100 Hz, acceleration of 19.6 m/s2, 60
minutes per cycle, repeat once in each X, Y
and Z-direction
Drop
Drop the scanner 30 times (6 faces x 5) from
the height of 150 cm onto a concrete floor
Environmental Specifications
Dust and drip proof IP42 equivalent
LED safety IEC 62471-1:2006 Exempt_Group
Peak Wavelength
624 nm
Product safety
EN60950-1:2005
IEC60950-1:2006
EMC
EN 55022:2010
EN 301 489-1 V1.9.2
EN 301 489-17 V2.1.1
EN 300 328 V1.8.1
FCC Part 15 Subpart C, Subpart B ClassB
VCCI Class B
For residential,
commercial and light-
industrial environments
Regulatory Compliance
Other
Bluetooth logo certification
MFi license
CE Marking
Certification for Construction Design of
Specified Radio Equipment
No distraction Air discharge (direct): ±15 kV
Immunity
Test
ESD
No malfunction
Contact discharge (direct / indirect): ±6 kV
Air discharge (direct): ±8 kV
Conditions:
IEC61000-4-2
compliant
Dimensions 113 × 56 × 132 (WDH mm)
Physical
Features
Weight Approx. 127 g
Excluding accessories
*1: When a bar code is read twice every 10 seconds at room temperature in a const Bluetooth connection (SPP
master mode).
