OPC-3301i
Specifications Manual
2
3. Basic Specifications
Item Specification Note
CPU 32 bit CISC / 96 MHz
FROM 512 Kbyte + 32 Kbyte
SRAM 96 Kbyte
Control
Section
FROM (storage) 1 Mbyte
For data area only
Input
Section
Key type 1 key: trigger
LED 2 colors (red, green) and 1 color (blue)
Buzzer Loudness (3-level) / tone adjustable
Indicator
Vibration motor Strength (3-level) / duration adjustable
Frequency 2402 ~ 2480 MHz
Specification Bluetooth Ver 2.1 compliant
Communication
distance
10 m
It may be shorter
depending on usage
environments
Output level Class 2
Max output 4 dBm
Interface
Bluetooth
Profile SPP / HID
Scan method CCD linear image sensor
Light source 1 red LED
Effective pixels 1500 pixels
Optical
Section
View angle Horizontal: approx. 50°
Symbologies
JAN, EAN, UPC-A, UPC-E, NW-7 (Codabar),
Industrial 2 of 5, Interleaved 2 of 5, Code 11，
Code 39，Code 93，Code 128 etc.
Refer to Chapter 17. for
details
Minimum resolution Code 39 : 0.1 mm
PCS 0.9
Curvature
R ≥ 15 mm (8-digit JAN)
R ≥ 20 mm (13-digit JAN)
PCS 0.9
Wide bar code
110 mm wide 0.2 mm resolution Code 39
(DOF 150 mm) is readable:
Pitch : ±50°
Skew : ±65° (excluding dead zone)
Scan angle
Tilt : ±25°
Resolution (0.127) 55 ~ 75
Resolution (0.15) 45 ~ 100
Resolution (0.25) 35 ~ 175
Resolution (0.5) 40 ~ 300
Depth of field
(mm)
Code 39
Resolution (1.0) 60 ~ 500
Supported 1D Symbologies
Minimum PCS 0.3 or more
MRD 32% or more
