0
1
2
3
4
5
6
7
8
9
END
Quick Start Instructions
Step 1 - Scan Bluetooth Mode
Scan the Bluetooth Default barcode that matches the connection
method you wish to use, HID (recommended) or SPP.
If you enable the iOS Keyboard Toggle feature by scanning the
ENABLE barcode, you will also be able to toggle the on-screen
keyboard of an iOS device by tapping the Clear/Function key.
Step 2 - Hold Clear/Function Key for 5 seconds
Hold the OPN2005’s Clear/Function key for 5 seconds until it
beeps and begins to flash blue. The OPN2005 is now discoverable
by your host device. This can be cancelled at any time by holding
the Clear/Function key for another 5 seconds.
Step 3 - Perform Bluetooth search on host
Use the Bluetooth interface on your host device to search for and
select the OPN2005. The OPN2005 will beep and the LED will flash
blue slower than before indicating pairing was successful. If you
are pairing in Bluetooth-SPP mode, the OPN2005 will complete the
pairing process as soon as you launch an appropriate application
and open the serial port created by your Bluetooth software.
For information about your OPN2005, including detailed setup
instructions, downloads and more, visit us at:
www.opticonusa.com/start/opn
