Connecting the Projector
Connect to Computer/Notebook
1
3
1....................................................................................................Power Cord
2....................................................................................................*USB Cable
3................................................................................................... *VGA Cable
4...........................................................................................*DVI/HDMI Cable
4
2
+ 12V Output
 Due to the
difference in
applications
for each
country, some
regions may
have different
accessories.
 (*) Optional
accessory
Note
Note
 “12V OUT” is only
for trigger control.
Not a power
supplier port.
 “12V OUT” is
activated when
the projector is
turned on and
continues to stay
on till you turn off
the projector.
