How to Install the Locking Screws
Note - The shelf rails must be inserted into the mounting bracket before performing this
procedure. They are shown separated in this picture to highlight the alignment.
Figure Legend
1 Screw
2 Cage nut (used for square hole racks only)
3 Rack
4 Rear mounting bracket
5 Shelf rail
2.
Repeat Step 1 for the other side.
