Manual for Tire Pressure Monitoring Systems, TPMS
12/20
Mode 1: Front to rear tires exchanged
Step
Operation process Photograph
1
Rotate the tires. Front to Rear, and Rear to Front. To
prevent incorrect positioning, mark the tires.
2
Press both the setup key and function key
simultaneously for 5 seconds. The display will flash green
and red, and a “beep” sound will be heard. You can release
the buttons, and the system will have entered into mode 1.
3
3-1
After entering mode 1, the display will show “ 1”,
3-2
LED lights will flash green for front tires, rear tires will flash
red. (Green means tires position before changing, Red
means after changing, it is to show that the front to rear tires
have been exchanged.)
3-3
The operator only needs to press the setup key for 1
second and listen for the “beep”. This means that mode 1
has been chosen and will exchange all four sensors ID
positions and will automatically return the monitoring status
to normal.
To Next Page
