2. Names and Functions of each part
2.1 Name of each part
Fuel Tank Cover
⑦Shift lever (during manual operation)
⑫Seat
steering wheel
HST Oil Thank
Fuel Tank Cap
Fuel tank
②Throttle lever
Side cowl (R)
Battery
⑦Change pedal
⑰Pilot lamp (Green)
⑱Hour meter
①Engine switch
Fuel gauge
③Choke lever
Mowing deck
Brake stopper
⑩Parking brake pedal
④Light Switch
Sub handle
Muffler exhaust port
Front hood
Side cowl (L)
⑥Blade clutch lever
Fuel cock
⑨Differential lock lever
⑤Cutting Height Adjustment Lever (Stepless with assistance)
⑪ Blade replacement
cover
⑭Fuse box
Rear frame
⑬Handle tilt lock lever
⑧Driving clutch lever
Slow blow fuse
(Back side of front hood)
⑯Engine oil warning light (Red)
⑮inclinometer
