Index
Item .................................... Page
《Introduction》 .............................. 1
《Definition and symbol mark》 ......... 1
《Regulation of this product》 ............ 2
《Important Notices》 ...................... 2
《Warranty / Contract / Disclaimer》 .. 2
1.
Before using〈Please read carefully for safe use〉
1.1 working conditions ................... 4
1.2 Before Working ....................... 4
1.2.1 Precautions before work ..... 4
1.2.2 Inspection before work ....... 5
1.2.3 No fires・Fuel supply .......... 6
1.3 During work ............................ 6
1.3.1
Precautions of while working . . . 6
1.3.2 Operational precautions ...... 7
1.3.3 Inspection while working・stop・
cleaning ............................. 7
1.4
Notes on loading and unloading ..... 8
1.5 Inspection / maintenance ......... 8
1.6 Storage .................................. 9
1.7Warning display mark ................ 9
2. Names and Functions of each part
2.1 Name of each part ................... 14
2.2 Function of each part ............... 15
①Engine switch .......................... 15
②Throttle Lever ......................... 15
③Choke lever ............................. 15
④Light Switch ............................ 15
⑤Cutting Height Adjustment ........ 15
⑥Blade clutch lever .................... 16
⑦
Change pedal・Speed Shift lever ........ 16
⑧Driving clutch lever .................. 16
⑨Differential lock lever ............... 17
⑩Parking brake pedal ................. 17
⑪Blade replacement cover .......... 17
⑫Seat(Seat slide and Seat suspension
functions Equipped.) ................. 18
⑬Handle tilt lock lever ................ 18
⑭Fuse box................................. 18
⑮inclinometer ............................ 18
⑯Engine oil warning light ............ 19
⑰Pilot lamp ............................... 19
⑱Hour meter ............................. 19
2.3 Direction of definition ............... 19
3. Inspection before work
3.1 Check engine oil ...................... 20
3.2 Fuel inspection and refueling ..... 21
4. Operation and work
4.1 Starting and stopping the engine ... 23
4.1.1 How to start the engine ....... 19
4.1.2 How to stop the engine ....... 25
4.2
Driving, Speed change,
Turning and Stopping
.......... 26
4.2.1 How to drive ....................... 26
4.2.2 How to stop (park) ............... 27
4.2.3 How to operate the
differential lock lever ...... 28
4.2.4 How to move
when it cannot run ............ 28
4.3 Loading and unloading,
Transportation. ................. 29
4.3.1 loading and unloading ........... 30
4.4 How to do the good work ........... 31
4.4.1
How to do the mowing work .. 32
4.5 Adjusting the handle and seat position
............................................... 35
4.6 How to use the moving light ....... 35
5. Inspection / maintenance / adjustment
5.1 Oil inspection / replacement /
lubrication .............................. 35
5.1.1 Inspection and replacement of
mission oil ........................ 35
5.1.2 Engine Oil check and change . 36
5.1.3 Oil filter replacement ............ 37
5.1.4 HST oil check and change ..... 37
5.1.5 lubrication for each part ........ 39
5.2 Engine related part cleaning,
inspection, and adjustment ... 40
5.2.1 Cleaning the air cleaner ........ 40
5.2.2
Checking and adjusting
the spark plug
....................... 41
5.2.3 Check the fuel pipe ............... 41
5.2.4 Check the fuel filter .............. 42
5.2.5 How to clean the engine
cooling system ................... 42
5.2.6 How to clean the engine
exhaust system ................... 43
5.3 Product Inspection and adjustment.
......................................... 43
5.3.1 Wire / belt adjustment
for each part ...................... 44
①Drive belt adjustment .............. 44
②Blade belt adjustment
(under seat bracket) ............... 45
③Adjusting the belt retainer
(under the seat bracket) .......... 45
④Blade brake adjustment ........... 46
⑤Parking brake adjustment ........ 46
⑥Adjusting the Speed shift lever . 47
