6.2 Tool bag details
NAME Spec / Size Qty remarks
instruction manual 1
1
Spanner 10×12 1
〃 14×17 1
L-type wrench 22mm 1 L-Type box wrench
Protective Gogel 0328-76100 1 Protective equipment
1
Setting bolts
Ｍ１４
2
For Blade front and back
replacement
Knife change 〃 1 Blade replacement tool
Maintenance tool 1
Cover removal tool
Hex wrench 3/8Inch 1
For HST oil drain
6.3 Consumable item details
Parts Name
Parts No Pcs/unit Remarks
Blade
0244-89100 2
Blade stay
0244-51100 1
Blade ＆ Set bolt kit
0244-78010 1
Set bolt kit
for Blade setting
0244-78210 2
Blade Change tool
0244-52400 1
Blade Change tool
Blade Collar
80-1483-818-00 2
Blade Set bolt
0207-50200 2 M14×32
Hard Lock nut M14
0244-74600 2 Special double net 1set
Nut guard
0244-51800 2 For M14
Cap Nut
83-1483-175-00 1
Fine nut、
M20
Spring washer
89-1750-200002 1
Φ
20
Blade stay set bolt
0244-51600 2
8T/M14×30
Spring washer
89-1750-140002 2
Φ
14
Battery (30A-19L)
80-1792-976-00 1
ＶBelt (Drive)
89-6123-003202 1
SＢ-32 W800
ＶBelt (Blade)
89-6123-008102 1
SＢ-81 W800
Tire tube (4.00-7)
80-1711-404-00 2
Front wheel tire tube
Tire tube (17×8.00-8)
0244-78300 2
Rear Wheel tire tube
Blade clutch wire
0322-75110 1
