9
The differentail lock lever can be “ON”only in straight line : never shift the differential lock
lever to”ON” position when turning.
The damage to the transmission will not be covered under warranty.
Fuel cock
The fuel cock is closed when machine is not use. Fuel cock is closed pushed rearward, and open
forward. (1, Figure 5bis)
Height of cut control
Height of cut can be setted by turning the bar (A
Figure 6, clockwise to increase the height of cut and
Counter-clockwise decrease the height of cut.
WARNING
Always perform this adjustment engine off and
sparking plug cover unplug
When cutting in low position, power needed and
thrown objects are more important. Cutting low
can cause damage to the machine and injury.
Figure 5 SH 61 (FJ180V)
Figure 5 SH 71H(GXV390)
Figure 6
Figure 6
