Oreck XL3910H2B User Manual

13
Part Numbers Listing: XL3640HH / U3640RH / XL3800H2B / XL3900H2B / XL3910H2B / U3980H2B / U3990H2B
Hypo Bag, Lights, Helping Hand Handle
#Item Order # Qty.Pk.
1Handle Assembly, Includes items #38, #53, #54, #55, #56, #57, #59 09-75288-02 1 1
Type 4 & 5 Units Only
1b Kit, Retro, Handle Assembly, Residential, White, includes items #38, 09-75612-01 1 1
#54, #55, #58, #59, #80, #81 Type 4 & 5 Units Only
4 Docking Clip, Rear, Type CC (use w/#67 or order #83) 75583-03-0000 1 1
5Dust Bag, (8 Pk.) Hypo Allergenic CCPK8DW 18
Dust Bag, (25 Pk.) Hypo Allergenic CCPK25DW 1 25
6 XL3640HH / XL3910H2B / U3990H2B: Outer Bag, Lt. Gray, Black, 75645-01 1 1
White Plus
U3640RH: Outer Bag, Dark Gray, Black, Dark Gray 75246-11 1 1
XL3800H2B: Outer Bag, Lt. Gray, Blk, Dark Gray 75246-10 1 1
XL3900H2B / U3980H2B: Outer Bag, Lt. Gray, Gold XL
2
Ultra 75246-31 1 1
7 XL3640HH / U3640RH: Bag Clip, Curved, Black w/White, Front 09-75594-02 1 1
XL3800H2B: Bag Clip, Black w/Silver 09-75078-06 1 1
XL3900H2B / XL3910H2B / U3980H2B / U3990H2B: Bag Clip, 09-75078-19 1 1
Black w/Gold
XL3900H2B / XL3910H2B / U3980H2B / U3990H2B: Bag Clip, 09-75594-01 1 1
Curved, Black w/Gold, Front
XL3640HH / U3640RH / XL3900H2B / XL3910H2B / U3980H2B / 75593-01-0327 1 1
U3990H2B : Bag Clip, Curved, Black, Rear
8 Connector Assembly Kit, includes items #3 & #84 09-75308-57 1 1
9Collar 75309-02-0327 21
10 Tube Assembly Type 4 Units Only 75188-01 1 1
Tube Assembly Type 5, 6 & 7 Units Only 75198-05 1 1
12 Fan Housing Assembly includes Rivet & Spring 09-75343-03 1 1
16 XL3800H2B / XL3900H2B / U3980H2B: End Cap, Plastic Pulley Brush Roll 0134623 1 1
XL3640HH / U3640RH / XL3910H2B / U3990H2B: Endcard, 75704-01 1 1
Metal Pulley Brush, Rt
18 METAXALLOY™ Fan Kit w/Washers 09-75300-01 1 1
19 Fan Cup Seal 75012-01 1 1
20 Cord Set see #59
21
Lamp Housing, Black 75521-01-0327 1 1
22 Lens 75520-02-455 1 1
23
Bulb 00965-0019 2 1
24 XL3640HH / U3640RH / XL3800H2B: Badge Decal, Silver 73020-02 1 1
XL3900H2B / XL3910H2B / U3980H2B / U3990H2B: 73020-01 1 1
Badge Decal, Gold
25 Lamp Holder 75539-01 1 1
26 Housing, Black 09-75780-17 1 1
27 XL3800H2B: Bumper, White 75181-03 1 1
XL3640HH / U3640RH / XL3900H2B / XL3910H2B / U3980H2B / 75181-04 1 1
U3990H2B: Bumper
, Clear
28 Intake Pivot Assembly with Felt Seal 09-75066-02 1 1
29 Felt Seal 75065-01 1 1
32
Felt Seal, Motor
751
17-01M
1
100
33 Cord Retainer, Square 03-00655-01 1 1
34
Motor
Assembly Kit
09-75505-01
11
35
Motor Seal
75095-01 2 1

Oreck XL3910H2B Specifications

General

Brand	Oreck
Model	XL3910H2B
Category	Vacuum Cleaner
Language	English
