14
36 Kit, Motor Brush / Spring 09-75514-01 2 2
3
9Drive Belt, (3 Pk.) 0300604 1 3
39a Drive Belt, Single 75024-01 1 1
4
0Door Belt, Black 75057-01-0327 1 1
42 XL3800H2B / XL3900H2B: Brush Roll, Plastic Pulley 75202-01 1 1
XL3640HH / U3640RH / XL3910H2B / U3980H2B / U3990H2B: 75104-02 1 1
Brush Roll, Metal Pulley
42a
XL3640HH / U3640RH / XL3910H2B / U3980H2B / U3990H2B: 75705-01 1 1
Endcard, Metal Pulley Side, Lft
42b XL3640HH / U3640RH / XL3910H2B / U3980H2B / U3990H2B: 75706-01 1 1
Brush Roll Pulley, Metal
43 Seal, Baseplate 75008-01 1 1
44 Plastic Detent, (uses 2 #49 screws) 75299-01 1 1
45 Complete Baseplate Assembly includes: #43, #46, #47, 09-75715-01 1 1
#50, #51, #52, #85, #86, #87
46 MICRO SWEEP Blade Type 4, 5 & 6 Units Only 75009-01 1 1
MICRO SWEEP Blade Type 7 Units Only 75700-02 1 1
47 Channel Type 4, 5 & 6 Units Only 75007-02 1 1
Channel Type 7 Units Only 75701-01 11
50 Edge Brush w/Wheels, Left Type 4, 5 & 6 Units Only 09-75249-02 1 1
Edge Brush w/Wheels, Right Type 4, 5 & 6 Units Only 09-75250-02 1 1
Edge Brush w/o Wheels, Left & Right 75766-02 2 1
51 Wheel Axle 03-00630-01M 2/4* 100
52 Soft Rear Wheel, Black 75187-02-0327 2 1
53 Static Wire Type 4 & 5 Units Only 75037-01 1 1
54 XL3640HH / U3640RH: Switch, 2 Position Assembly, Lighted 75523-03 1 1
Switch, 3 Position Assembly w/Diode Type 4 & 5 Units Only 75320-01 11
Switch, 3 Position Assembly w/Diode Type 6 & 7 Units Only 75585-01 1 1
55 Grips, Black Set Type 4 & 5 Units Only 09-75301-02 1 1
Grips, Black Set Type 6 & 7 Units Only 09-75576-02 1 1
56 Cord Wrap Assembly w/Post and Cord Wrap 09-75185-01 1 1
57 XL3640HH / U3640RH / XL3800H2B / XL3900H2B / 75190-03 1 1
U3980H2B: Handle Tube, Chrome
XL3910H2B / U3990H2B: Handle
T
ube, Black
75190-04
1
1
58 XL3640HH / U3640RH: Cord, Harness Assembly, Black 75600-02-327 1 1
Cord, Harness Assembly, Black T
ype 4 & 5 Units Only
75081-02 11
Cord, Harness Assembly, Black Type 6 & 7 Units Only 75552-02-327 1 1
59 Cord Set, Black Type 4 & 5 Units Only 75292-01-327 1 1
Cord Set, Black w/ #81 Type 6 & 7 Units Only 75556-02-327 1 1
60 Motor Spring 75283-01 2 1
61 Tube Label 75087-05 1 1
67 Bag Dock Hinge, Type CC (use w/#4 or order #83) 75582-03-0000 1 1
User
’
s Manual 75416-05 1 1
Magnet Clean V
acuum Protector MC4BK 1 1
79
Stiffener (uses same length screws, notched) 75189-02 1 1
Stiffener, Through Bolt Connector (uses different length screws) 75619-01 1 1
81
Cord Flex Relief
T
ype 6 & 7 Units Only
03-00600-01
1
1
83
Kit, Bag Dock, includes items #4 & #67 09-75657-01 1 1
87
Front Wheel
T
ype 7 Units Only
75709-01
21
*Type 7 Units
Part Numbers Listing: XL3640HH / U3640RH / XL3800H2B / XL3900H2B / XL3910H2B / U3980H2B / U3990H2B cont.
Hypo bag, lights, Helping Hand handle
# Item Order # Qty. Pk.
To Next Page
