Oreck XL3910H2B User Manual

Part Numbers Listing: XL3600HH / XL3600RH / XL3610HH / U3700HH / U3710HH
Hypo Bag, Lights, Helping Hand Handle
# Item Order # Qty. Pk.
1 XL3600HH / XL3600RH: Handle Assembly, includes items #38, 09-75288-16 1 1
#53, #54, #55, #56, #57, #59 Type 4 & 5 Units Only
X
L3610HH:
H
andle Assembly,
i
ncludes items #38, #53, #54,
0
9-75288-17 1 1
#55, #56, #57, #59 Type 4 & 5 Units Only
1b Kit, Retro, Handle Assembly, Residential, White, includes items #38, 09-75612-01 1 1
#
54, #55, #58, #59, #80, #81
Type 4 & 5 Units Only
4 Docking Clip, Rear, Type CC (use w/#67 or order #83) 75583-03-0000 1 1
5 Dust Bag, (8 Pk.) Hypo Allergenic CCPK8DW 1 8
Dust Bag, (25 Pk.) Hypo Allergenic CCPK25DW 1 25
6 XL3600HH / XL3610HH: Outer Bag, Lt. Gray, Black, Dark Gray 75246-10 1 1
XL3600RH: Outer Bag, Dk Gray, Gold Anniversary 75246-29 1 1
U3700HH / U3710HH: Outer Bag, Lt Gray, Blue, Silver Plus 75645-03 1 1
7 XL3600HH / XL3600RH: Bag Clip, White w/Gold 09-75078-17 1 1
XL3610HH: Bag Clip, White w/Black 09-75078-05 1 1
U3700HH: Bag Clip, White w/Blue 09-75078-21 1 1
U3710HH: Bag Clip, White w/Silver 09-75078-22 1 1
8 Connector Assembly Kit, includes items #3 & #84 09-75308-57 1 1
9 Collar 75309-02-0327 2 1
10 Tube Assembly Type 4 Units Only 75188-01 1 1
Tube Assembly Type 5, 6 & 7 Units Only 75198-05 11
12 Fan Housing Assembly includes Rivet & Spring 09-75343-03 1 1
16 XL3600HH / XL3600RH / XL3610HH: End Cap, Plastic Pulley Brush Roll 0134623 1 1
U3700HH / U3710HH: Endcard, Metal Pulley Brush, Rt 75704-01 1 1
18 METAXALLOY™ Fan Kit w/Washers 09-75300-01 1 1
19 Fan Cup Seal 75012-01 1 1
20 Cord Set see #59
21 Lamp Housing, White 75521-01-0431 1 1
22 Lens 75520-02-455 1 1
23 Bulb 00965-0019 2 1
24 XL3600HH / XL3600RH / XL3610HH: Badge Decal, Gold 73020-01 1 1
U3700HH / U3710HH: Badge Decal, Blue 73020-03 1 1
25 Lamp Holder 75539-01 1
1
26 Housing, White 09-75780-1
1
11
27 Bumper, White 75181-03 1 1
28 Intake Pivot Assembly, with Felt Seal 09-75066-02 1 1
29 Felt Seal 75065-01 1 1
32
Felt Seal, Motor
751
17-01M
1
100
33
Cord Retainer
, Square 03-00655-01 1
1
34 Motor Assembly Kit 09-75505-01 1 1
35 Motor Seal 75095-01 2 1
36 Kit, Motor Brush / Spring 09-75514-01 2 2
39 Drive Belt, (3 Pk.) 0300604 1 3
39a Drive Belt, Single 75024-01 1 1
40 Door Belt, White 75057-01-0431 1 1
7
