Part Numbers Listing: XL3600HH / XL3600RH / XL3610HH / U3700HH / U3710HH cont.
Hypo Bag, Lights, Helping Hand Handle
# Item Order # Qty. Pk.
42 XL3600RH / XL3610HH: Brush Roll, Plastic Pulley 75202-01 1 1
XL3600HH / U3700HH / U3710HH: Brush Roll, Metal Pulley 75104-02 1 1
42a XL3600HH / U3700HH / U3710HH: Endcard, Metal Pulley Side, Lft 75705-01 1 1
42b
XL3600HH / U3700HH / U3710HH: 75706-01 1 1
Pulley, Metal (For Brushroll)
43 Seal, Baseplate 75008-01 1 1
44 Plastic Detent, (uses 2 #49 screws) 75299-01 1 1
45 Complete Baseplate Assembly includes: #43, #46, #47, 09-75715-01 1 1
#50, #51, #52, #85, #86, #87
46 MICRO SWEEP Blade Type 4, 5 & 6 Units Only 75009-01 1 1
MICRO SWEEP Blade Type 7 Units Only 75700-02 1 1
47 Channel Type 4, 5 & 6 Units Only 75007-02 1 1
Channel Type 7 Units Only 75701-01 1 1
50 Edge Brush w/Wheels, Left Type 4, 5 & 6 Units Only 09-75249-02 1 1
Edge Brush w/Wheels, Right Type 4, 5 & 6 Units Only 09-75250-02 1 1
Edge Brush w/o Wheels, Left & Right 75766-02 2 1
51 Wheel Axle 03-00630-01M 2/4* 100
52 Soft Rear Wheel, Black 75187-02-0327 2 1
53 Static Wire Type 4 & 5 Units Only 75037-01 1 1
54 Lighted 2 position Switch Kit Type 4 & 5 Units Only 09-75523-01 1 1
Switch, 2 Position Assembly, Lighted Type 6 & 7 Units Only 75523-03 1 1
55 Grips, White Set Type 4 & 5 Units Only 09-75301-19 1 1
Grips, White Set Type 6 & 7 Units Only 09-75576-19 1 1
56 Cord Wrap Assembly w/Post and Cord Wrap 09-75185-05 1 1
57 XL3600HH / XL3600RH / U3700HH: Handle
Tube, Chrome
75190-03 1 1
XL3610HH / U3710HH: Handle Tube, Black 75190-04 1 1
58 Cord, Harness Assembly, White Type 4 & 5 Units Only 75081-01 1 1
Cord, Harness Assembly, White Type 6 & 7 Units Only 75600-02-328 1 1
59 Cord Set, White Type 4 & 5 Units Only 75522-01-328 1 1
Cord Set, White w/ #81 Type 6 & 7 Units Only 75556-02-328 1 1
60
Motor Spring
75283-01
2
1
61 Tube Label 75087-05 1 1
67 Bag Dock Hinge, Type CC (use w/#4 or order #83) 75582-03-0000 1 1
68 Receptacle Type 4 & 5 Units Only 75524-01 1 1
User
’
s Manual 75416-05 1
1
Magnet Clean Vacuum Protector MC4BK 1 1
79 Stiffener (uses same length screws, notched) 75189-02 1 1
Stiffener, Through Bolt Connector (uses different length screws) 75619-01 1 1
81 Cord Flex Relief T
ype 6 & 7 Units Only
03-00600-01 1
1
83 Kit, Bag Dock, includes items #4 & #67 09-75657-01 1 1
87
Front Wheel
T
ype 7 Units Only
75709-01
21
*Type 7 Units
8
