6
Installation
4. Sensor pad installation:
• When using for infant not yet able to crawl, place one sensor pad as
shown in illustration 3. Make sure the sensor is placed underneath
baby’s location in crib.
• When baby begins to crawl, and is able to move onto areas not
"covered" by a single sensor pad, attach the second sensor and place
the two sensors as shown in illustration 3.
PLEASE NOTE: The sensors shall be placed with the marking “THIS SIDE
UP” facing upwards.
Sensor pads
(Under mattress)
Control unit
Illustration 3
Top crib/cot view
For babies not
yet able to crawl
For crawling babies
Top crib/cot view
5. Pass the cord(s) of the sensor pad(s) through special openings in the
holder as shown in illustration 4.
Illustration 4
Control unit
holder
PLEASE NOTE: DO NOT ATTACH THE CONTROL UNIT TO THE TOP RAIL
OF THE COT. DO NOT EXTEND CABLES IN ANYWAY.
