Overview of the Parent Unit
2 43
8
10
9
5
6
11
12
13
7
16
17
18
15
14
1
1. Display (LCD screen)
2. Charging LED
RED when mains power
connected.
3. Parent Unit ON/OFF LED
(Green)
4. Sound Level indicators (Green,
Amber, Red, Red)
Show the sound level detected
by the Baby Unit - the louder of
sound detected, the more LEDs
light up.
5. Volume -
Press to decrease Volume level.
6. Volume +
Press to increase Volume level.
7. Display ON/OFF button
Press to turn the LCD screen
ON/OFF (Note: audio is
maintained.)
8. Microphone
9. MENU button
Press to open / close the Menu
options.
10. Navigation button
+ - < >
Move Up/Down/Right/Left menu
options.
11. OK button
12. TALK button
T
Press and hold to speak to your
baby.
13. Power button
0
Press and Hold to turn the Parent
Unit ON/OFF.
14. Antenna
15. RESET pin hole (recessed - use
small pin)
16. Speaker
17. Power Socket
18. Stand
