Oricom TPS10 - Controls and Indicators

5
Controls and Indicators
Controls and Indicators
Psi
Psi Psi Psi
Trailer interface Spare interface
Tow vehicle interface
Select button
Display battery indicator
Temperature data
SET button
Solar panel
Ventilation holes
Micro USB input
Charging status
Pressure data
Axles of trailer
Temperature unit
Pressure unit
Warning indicator
Note: The icon in the centre of the LCD display indicates the viewing interface.
