Oricom TPS10 User Manual

7
Sensor Installation
Sensor Position
Sensor Installation
Sensor position
Psi Psi Psi
F.L. F.R.
R.L. A3R.R.
A1 A2 S1 S2
A4
F.R.
R.R.
R.L.
F.L.
A2
A4
A3
S2 S1
A1
Note: Typical sensor position as
per diagram to the left.
1.Unscrew the valve cap. 2.Insert the dustproof cover onto the valve stem.
3.Screw on the nut. 4.Screw on the sensor.
Note: Axle B not in use
Note: Depending on pack purchased you may have up to 10 sensors.
Tow Vehicle
Trailer Spares
Note: Do not over-tighten sensors as this will effect the readings.

Oricom TPS10 Specifications

General

Brand	Oricom
Model	TPS10
Category	Measuring Instruments
Language	English
