Specications
47
z
300 W and 400 W
Model
Motor
BLM6300SHP
BLM5300HP
BLM6400SHP
BLM5400HP
Driver
BLE2D300-C BLE2D400-S
Rated output power (Continuous) 300 W 400 W
Power
supply
input
Rated voltage
Single-phase 200-240 VAC
Three-phase 200-240 VAC
Three-phase 200-240 VAC
Permissible voltage range -15% to +10%
Rated frequency 50/60 Hz
Permissible frequency range ±5%
Rated input current
Single-phase: 3.2 A
Three-phase: 1.8 A
Three-phase: 2.3 A
Maximum input current
Single-phase: 8.5 A
Three-phase: 6.0 A
Three-phase: 6.1 A
Rated torque 0.955 N·m 1.27 N·m
Peak torque 1.72 N·m (80 to 2000 r/min) 2.28 N·m (80 to 2000 r/min)
Rated rotation speed 3000 r/min
Speed control range
80 to 4000 r/min
*
*
There are products which maximum rotation speed is 3600 r/min depending on the type of gearhead.
Check the operating manual included with the motor.
2. General specications
Operating
environment
Ambient temperature
Driver: 0 to +50 °C [+32 to +122 °F] (non-freezing)
*
Ambient humidity 85% or less (non-condensing)
Altitude Up to 1000 m (10000 ft.) above sea level
Surrounding
atmosphere
No corrosive gas or dust. Not exposed to oil. Cannot be used in radioactive materials, magnetic eld,
vacuum or other special environment. (For details about installation locations, refer to p.12.)
Vibration
Not subject to continuous vibrations or excessive impact.
In conformance with JIS C 60068-2-6 "Sine-wave vibration test method"
Frequency range: 10 to 55 Hz Pulsating amplitude: 0.15 mm (0.006 in.)
Sweep direction: 3 directions (X, Y, Z) Number of sweeps: 20 times
Storage
environment
Shipping
environment
Ambient temperature Driver: −25 to +70 °C [-13 to +158 °F] (non-freezing)
Ambient humidity 85% or less (non-condensing)
Altitude Up to 3000 m (10000 ft.) above sea level
Surrounding
atmosphere
No corrosive gas, dust, water or oil. Cannot be used in radioactive materials, magnetic eld, vacuum or
other special environment
Degree of protection Driver: IP20
*
The conditions of use vary when two or more drivers are installed closely in the horizontal direction. Refer to p.13 for details.
3. Pin assignment
The pin assignments of the connectors for driver connection of the connection cable are shown here. The following gures
represent as the view from the direction of the lead wires side of the connection cable.
•
Power connector (white) CN2
6
5
4
3
2
1
Housing: 5557-06R-210
(molex)
Terminal: 5556T (molex)
•
Sensor connector (black) CN4
32
1
32
1
B
A
Housing:
J11DF-06V-KY
(J.S.T. Mfg. Co.,Ltd.)
Terminal:
SF1F-002GC-P0.6
(J.S.T. Mfg. Co.,Ltd.)
Pin No. Lead wire color Lead wire size Pin No. Lead wire color Lead wire size
1 Blue AWG18 A3 − −
2 − − A2 Green
AWG26
3 −
Drain
AWG24 or equivalent
A1 Yellow
B3 Brown
4 Purple
AWG18
B2 Red
5 Gray B1 Orange
6 − −
•
Electromagnetic brake connector (white) CN3
*
Pin No. Lead wire color Lead wire size
21
Housing: 5557-02R-210
(molex)
Terminal: 5556T (molex)
1 Black
AWG22
2 White
*
Only drivers for electromagnetic brake motor
