19
Installation and User’s Guide
htt
p
://www.orionima
g
es.com
7300 Bolsa Avenue, Westminster CA 92683 / Tel: 714-766-6300 / Fax: 714-766-6310
pg19
OSD (On Screen Display) SETTING
E. PVM Setup Menu
1. MOTION MODE
2. MOTION INPUT
3. DWELL
Sets the video input which will be displayed when motion signal. (FULL /PIP/ DW1 / DW2)
Select the input source of motion mode (VIDEO1 / VIDEO2 / S-VIDEO).
Sets the time how long displayed on the screen of motion mode from 10 seconds to 60 seconds.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Orion 20" and is the answer not in the manual?

Orion 20" Specifications

General IconGeneral
Screen Size20 inches
Resolution1600x900
Aspect Ratio16:9
Panel TypeTN
Refresh Rate60 Hz
Response Time5ms
Brightness250 cd/m²
Contrast Ratio1000:1
Viewing Angle170°/160°
Input PortsVGA, DVI
Power Consumption25W
