APPENDIX
PIN NO. PIN Name PIN NO. PIN Name
1
RED VIDEO
9
NC
2
GREEN VIDEO
10
SIGNAL CABLE DETECT
3
BLUE VIDEO
11
GROUND
4
GROUND
12
SDA (for DDC)
5
GROUND
13
H-SYNC
6
RED GROUND
14
V-SYNC
7
GREEN GROUND
15
SCL (for DDC)
8
BLUE GROUND
5.1 D-SUB Connector PIN Assignment
