Orion 20" User Manual

5
Installation and User’s Guide
htt
p
://www.orionima
g
es.com
7300 Bolsa Avenue, Westminster CA 92683 / Tel: 714-766-6300 / Fax: 714-766-6310
pg5
TABLE OF CONTENTS
1. INSTALLATION
.................................................................................................................
1.1 Parts
……....................................................................................................................
2. FEATURES
…................................................................................................................
2.1 Specifications (General)
…….……..........................................................................
3. OSD SETTING
..........................................................................................................
7. TROUBLESHOOTING
..
....
.
.......................................................
...............
..
.................
..
8. LIMITED LIFETIME WARRANTY
..
....
.
.......................................................
.................
..
4. CONTROL AND FUNCTIONS
..
....
.
................
.................
.......
......
..........
....................
....
1.2 Connection
(
20 Inch
)
…..…...........................................................................................
6. INFORMATION TO THE USER
..
....
.
.......................................................
................
.......
.
1.3 Connection
(
26 & 32 Inch
)
..……...............................................................................
1.4 Remote Controller
..……...........................................................................................
3.1 OSD Menu Description (20 Inch)
.........................................................................
3.2 OSD Menu Description (26 & 32 Inch)
...............................................................
5. APPENDIX
..
....
.
.......................................................
................
.......................................
2.2 Specifications (Card Reader)
…….……...................................................................
6
6
10
10
12-20
24
25
21
7
23
8
9
12-15
16-20
22
11

Orion 20" Specifications

General

Screen Size	20 inches
Resolution	1600x900
Aspect Ratio	16:9
Panel Type	TN
Refresh Rate	60 Hz
Response Time	5ms
Brightness	250 cd/m²
Contrast Ratio	1000:1
Viewing Angle	170°/160°
Input Ports	VGA, DVI
Power Consumption	25W
