INSTALLATION
A. SOURCE SELECT
B. PVM INPUT (Not Available on this Model)
C. PIP MENU
1.3 Remote Controller
Press the button to select the desired input source
POWER
Turn the monitor ON or OFF
MUTE
Temporarily silences the sound
COLOR TEMP
Adjust the color temperature of the screen.
SCAN MODE
Change the scan mode of the screen. (FULL / UNDER / OVER)
MENU/EXIT
Activates and exits the OSD menu
KEY LOCK
Prevent unauthorized operation of the equipment by locking the
buttons
STILL
PIP: Activates/deactivates PIP/PBP mode
PIP: Activates/deactivates PIP/PBP mode
P. LOC: Selects a location for the sub picture
P. SWAP: Swaps the main and sub picture
P. SET: Alternates between main and sub audio input
P. INPUT: Selects an in
p
ut source for the sub
p
icture
P. SIZE: Selects the size of the sub picture
