BRIDGED MODE
SPEAKERS CONNECTIONS
CB1500.4/CB2000.4
MONO SPEAKER
4~8Ohm
MONO SPEAKER
4~8Ohm
BRIDGED
REM GND
+12V
POWER INPUT
CH1 CH2
CH3 CH4
FUSES
SPEAKER OUTPUT
CB600.4/CB1000.4
MONO SPEAKER
4~8Ohm
MONO SPEAKER
4~8Ohm
BRIDGED
REM GND
+12V
POWER INPUT
CH1 CH2
CH3 CH4
FUSES
SPEAKER OUTPUT
CB2400.1D2
POWER INPUT
SPEAKER OUTPUT
+12V
REM GND
FUSES
30A X 4
MIN 2
+ +
MONO SPEAKER
2~4Ohm
REM
POWER INPUT
SPEAKER OUTPUT
+12V
GND
+ +
MONO SPEAKER
2~4Ohm
CB5000.1D
CB600.4:30Ax2
CB1000.4:35Ax2
CB1500.4:30Ax3
CB2000.4:35Ax3
CB5000.1D:250A
