SPEAKERS CONNECTIONS SPEAKERS CONNECTIONS
CB1200.1D
POWER INPUT
SPEAKER OUTPUT
FUSES
+12V
REM GND
MIN 1
30A X 3
+ +
MONO SPEAKER
1~4Ohm
CB700.1M2
+ +
MONO SPEAKER
2~4Ohm
CB1100.1M2
+ +
MONO SPEAKER
2~4Ohm
FUSES
POWER INPUT
SPEAKER OUTPUT
REM+12V GND
MIN 2
25A X 2
FUSES
POWER INPUT
SPEAKER OUTPUT
REM+12V
GND
MIN 2
30A X 3
CB2400.1D
POWER INPUT
SPEAKER OUTPUT
+12V
REM GND
FUSES
30A X 4
MIN 1
+ +
MONO SPEAKER
1~4Ohm
CB3200.1D
POWER INPUT
SPEAKER OUTPUT
+12V
REM GND
FUSES
30A X 5
MIN 1
+ +
MONO SPEAKER
1~4Ohm
