INTRODUCTION
Thank you for your purchase of a West Coast Customs by Orion power amplifier. Each WCC
amplifier is designed to be the leader in its class offering the most power, advanced fea-
tures, and extreme ease of use. In high-end sound systems or high SPL systems, WCC ampli-
fiers will give you years of trouble-free performance.
● WCC-D2400 - 1200 Watt single-channel Class D amplifier with built-in fully vari-
able high-pass, low-pass, or band-pass crossover with INTELLi Q. Equipped with
optional remote gain, the D2400 is capable of one-channel operation with a max-
imum power of 1200 Watts into 1W.
● WCC-D5000 - 2500 Watt single-channel Class D amplifier with built-in fully vari-
able high-pass, low-pass, or band-pass crossover with INTELLi Q. Equipped with
optional remote gain, the D5000 is capable of one-channel operation with a max-
imum power of 2500 Watts into 1W.
The installation of all WCC components will determine the overall performance result.
Improper installation will not only limit the performance of your WCC system but also
potentially compromise the reliability of this amplifier. To ensure proper sonic results and
component reliability, please refer to your authorized dealer for installation assistance or
advice. If you decide to perform the installation yourself, be sure to read the entire manu-
al before beginning the installation.
What’s in the Box
● (1) Amplifier
● (1) Spare fuse(s) (WCC-D2400 only)
● (1) Allen wrench 2.5mm
● (1) Allen wrench 3mm
● (4) #8 self-tapping black Phillips head pan head screws
● (1) Amplifier installation and operation manual
PRACTICE SAFE SOUND™
Continuous exposure to sound pressure levels over 100dB may cause permanent hearing
loss. High power automotive sound systems can generate sound pressure levels in excess of
130dB. When playing your system at high levels, please use hearing protection and avoid
long term exposure.
2
©2004 Directed Electronics, Inc.
