5
©2004 Directed Electronics, Inc.
12. Speaker Connections - accepts up to 12-gauge speaker wire.
13. Remote Gain Jack - connects optional RGC-1 (remote gain control).
14. 3 ATC Fuses (WCC-D2400) - protects the amplifier from over current situations.
15. Power Connections - accepts up to 4 AWG power and ground cables.
16. Additional Power Connectors (WCC-D5000) - accepts secondary power and
ground cables.
17. REM Remote Turn-on Input - turns on the amplifier when fed 12 V+.
