Orion HCCA10002 User Manual

© 2009 Directed Electronics. All rights reserved. 6
CEA SPECIFICATIONS
HCCA10002
Power Output: 250 Watts RMS x 2 at 4 ohms and
< 1% THD+N
Signal to Noise Ratio: >70 dBA (reference 1 Watt
into 4 ohms)
Additional Power: 500 Watts RMS x 2 at 2 ohm
at 14.4 Supply < 1% THD+N
HCCA10004
Power Output: 125 Watts RMS x 4 at 4 ohms and
< 1% THD+N
Signal to Noise Ratio: >70 dBA (reference 1 Watt
into 4 ohms)
Additional Power: 250 Watts RMS x 4 at 2 ohm
at 14.4 Supply <1% THD+N
SPECIFICATIONS
Amplifier Section HCCA10002 HCCA10004
Power Output 4Ω (Watts
rms) *
250 x 2 125 x 4
Power Output 2Ω (Watts
rms) **
500 x 2 250 x 4
Power Output 4Ω (Watts
rms) Bridged
1000 x 1 500 x 2
Amplifier Efficiency > 60% into 2Ω load
at max. power
> 55% into 2Ω load
at max. power
Signal to Noise ratio at
rated output power and
lowest impedance
>100dB >100dB
Remote Gain Function Yes (RGC2 optional) Yes (RGC2 optional)
Distortion at Rated Power 0.05% THD+N 0.05% THD+N
Frequency Response 20Hz to 20kHz
+/- 2.5dB
20Hz to 20kHz
+/- 2.5dB
Linear Bandwidth 10Hz to 150kHz
+/- 3dB
10Hz to 150kHz
+/- 3dB
Damping Factor > 200 > 200
Input Sensitivity Selection
Switch
Yes Yes
Input Sensitivity 200mV-4V / 400mv-8V 200mV-4V / 400mv-8V
Supply Voltage Range 9 to 16V 9 to 16V

Orion HCCA10002 Specifications

General

Brand	Orion
Model	HCCA10002
Category	Car Amplifier
Language	English
