Orion RKS400F-S User Manual

28
Troubleshooting
Alarm Types and Product Response Chart
Alarm Types and Product Response Chart
■Alarm List
Alarm
number
Name
Actions in
response to
alarms
Operation
signal
Alarm
signal
Display Restore
C00 500-hour filter use caution alarm
Running
○ ×
Alternate
dis
p
la
y
s
Manual
E01 Compressor motor protector
All stopped
× ○
Alternate
dis
p
la
y
s
Manual
E02 High pressure switch
All stopped
× ○
Alternate
dis
p
la
y
s
Manual
E04 Compressor intake temperature sensor
All stopped
× ○
Alternate
dis
p
la
y
s
Manual
C07 Liquid temperature limit alarm
Running
○ ○
Alternate
dis
p
la
y
s
Auto
C08 Compressor stop less than 3 minutes
Running
○ ×
Alternate
dis
p
la
y
s
Auto
E09 Power phase loss(RKS500,750F)
All stopped
× ○
Blinking
Power-on
E10 Power phase reversal(RKS500,750F)
All stopped
× ○
Blinking
Power-on
E11
Liquid temperature sensor failure
(measured temperature low)
All stopped
× ○
Blinking
Manual
E12
Liquid temperature sensor failure
(measured temperature high)
All stopped
× ○
Blinking
Manual
E13 Memory error
All stopped
× ○
Blinking
Power-on
E14 Power suspension recovery
All stopped
× ○
Alternate
dis
p
la
y
s
Manual
E15 Other error
All stopped
× ○
Blinking
Manual
※The symbol ○ for signals indicates that a signal is output，and the symbol × , that no signal is
output.
※The operating signal and an alarm signal behaviors represent the cases where the respective alarm is
generated by itself.
※Even with an alarm that sustains a signal generation, the operating signal is suspended if other alarms
are generated in conjunction and the compressor shuts down.
※"Alternate display" in the Display column indicates that the water temperature measurement and the
alarm number are displayed in turn. "Blinking" indicates that the relevant alarm number blinks.
※E14 only outputs a signal when "0" (default) is selected for the F1 parameter.
