Orion RKS400F-S User Manual

52
External dimensions
■RKS500F
Drain
(M10 female screw)
67 350
Detailed drawing of operation panel
Setting"UP"switch
Setting"DOWN"switch
Setting swi
tch
Operation lamp
switch Operation,Stop
Alarm reset switch
Indicator
（Temperature，Alarm）
Hot air outlet
Hot air outlet
With diaphragmed grommet
Power cord hole(φ30 hole)
385
55
3
4
Water Inlet(Rp3/4)
23
32
Priming water inlet
Operation panel
Filter
Hot air outlet
Air suction
Hot air outlet
47
52 270(right)
222(left)
51
138.5175
325 8
42 397
375
85 220
76
72187
92 150
363
242
484
Handle
φ11 hole
2-φ11 hole
ＳＥＴ
ＯＮ
ＯＦＦ
ＲＥＳＥＴ ＡＬＡＲＭ
℃
ＣＯＯＬＥＲ
ＳＥＴ
ＯＮ
ＯＦＦ
ＲＥＳＥＴ
ＡＬＡＲＭ
℃
ＣＯＯＬＥＲ
Water outlet(Rp3/4)
( Unit:mm )
