External dimensions
■RKS750F
Before side Back side
Filter
Hot air outlet
Priming water inlet
Operation panel
Water Inlet(Rp3/4)
Drain
Handle
φ11 hole
2-φ11 hole
Power cord hole(φ30 hole)
Setting"UP"switch
Setting"DOWN"switch
Setting switch
Operation lamp
switch
Alarm reset switch
Indicator
8390
45
73237
52
52 270(right)
222（left）
67 400 30
32
3
4
415
85 265
72.5
175 126
18.5 497
405
534
247
428
92 155
70
Hot air outlet
Hot air outlet
(M10 female screw)
Hot air outlet
Air suction
With diaphragmed grommet
ＳＥＴ
ＯＮ
ＯＦＦ
ＲＥＳＥＴ
ＡＬＡＲＭ
℃
ＣＯＯＬＥＲ
Detailed drawing of operation panel
Operation,Stop
（Temperature，Alarm）
ＳＥＴ
ＯＮ
ＯＦＦ
ＲＥＳＥＴ
ＡＬＡＲＭ
℃
ＣＯＯＬＥＲ
Water outlet(Rp3/4)
( Unit:mm )
