SPECIFICATIONS
Amplifier Section XTR5001 XTR10001 XTR15001
Power Output 4Ω
(Watts) *
150 x 1 300 x 1 400 x 1
Power Output 2Ω
(Watts) **
300 x 1 600 x 1 800 x 1
Power Output 1Ω
(Watts)
600 x 1 1200 x 1 1600 x 1
Amplifier Efficiency 80% 80% 80%
Signal to Noise ratio
at rated output power
and lowest impedance
>65dB >65dB >65dB
Externally Bridgeable Yes Yes Yes
Remote Gain Function Yes (RGC2 sup-
plied)
Yes (RGC2 sup-
plied)
Yes (RGC2 sup-
plied)
Distortion at Rated
Power
0.5% THD+N 0.5% THD+N 0.5% THD+N
Frequency Response 20Hz to 300Hz
+/- 2.5dB
20Hz to 300Hz
+/- 2.5dB
20Hz to 300Hz
+/- 2.5dB
Linear Bandwidth 20Hz to 300Hz
+/- 3dB
20Hz to 300Hz
+/- 3dB
20Hz to 300Hz
+/- 3dB
Damping Factor 50 50 50
Input Sensitivity (rms) 200mV to 8V 200mV to 8V 200mV to 8V
Input Sensitivity
Selection Switch
Yes Yes Yes
Supply Voltage Range 9 to 16V 9 to 16V 9 to 16V
Amplifier Section XTR5001 XTR10001 XTR15001
Protection Thermal, DC offset, short protection, under-
voltage
Terminal Wire Gauge Power 4 AWG
Remote
12 AWG
Ground 4 AWG
Speaker 12
AWG
Power 4 AWG
Remote
12 AWG
Ground 4 AWG
Speaker 12
AWG
Power 4 AWG
Remote
12 AWG
Ground 4 AWG
Speaker 12
AWG
Input Impedance 20kΩ 20kΩ 20kΩ
Dimensions (inches)
10.3 x 9.3 x 2.5 11.5 x 9.3 x 2.5 14.25 x 9.3 x 2.5
Crossover Section
Phase Switch (0° or
180°)
Yes Yes Yes
Crossover slope Selectable: Off,
12dB, 24dB
Selectable: Off,
12dB, 24dB
Selectable: Off,
12dB, 24dB
Low Pass Crossover Continuously
variable
(30-250Hz)
Continuously
variable
(30-250Hz)
Continuously
variable
(30-250Hz)
Infrasonic (subsonic)
Filter
Selectable
On/Off 12dB/
Octave
12dB at 24Hz
Selectable
On/Off 12dB/
Octave
12dB at 24Hz
Selectable
On/Off 12dB/
Octave
12dB at 24Hz
Bass Boost 0 - 18dB boost 0 - 18dB boost 0 - 18dB boost
* Continuous 4Ω load 20Hz-200Hz, < 1% THD, with input voltage at 14.4 VDC.
** Continuous 2Ω load 20Hz-200Hz, < 1% THD, with input voltage at 14.4 VDC.
