Page 34
Product Specication Manual - Osburn 1700-I
ENGLISH
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts
for this unit, please provide the model number and the serial number. We reserve the right to
change parts due to technology upgrades or availability. Contact an authorized dealer to obtain
any of these parts. Never use substitute materials. Use of non-approved parts can result in poor
performance and safety hazards.
# Item Description Qty
1 AC01299 RIGID FIRESCREEN 1
2 30898 ROUND WOODEN BLACK HANDLE 2
3 OA10249 BLACK DOOR OVERLAY 1
4 SE24298 OSBURN 1700 DOOR ASSEMBLY 1
5 AC06500 SILICONE AND 5/8" X 8' BLACK DOOR GASKET KIT (AC-DGKNC) 1
6 30101 SPRING TENSION PIN 5/32"Ø X 1 1/2"L 1
7 SE74166 HANDLE 30898 REPLACEMENT KIT 1
8 SE65024 REPLACEMENT HANDLE WITH LATCH KIT 1
9 AC09185 DOOR LATCH KIT 1
10 SE70676 ARCHED GLASS WITH GASKET 16 3/4"W X 10 7/16"H 1
11 AC06400 3/4" X 6' FLAT BLACK SELF-ADHESIVE GLASS GASKET (AC-GGK) 1
12 SE70727 GLASS AND MOULDING KIT 1
13 PL75123 GLASS FRAME MOULDING 2
14 SE53585 GLASS RETAINER KIT WITH SCREWS (12 PER KIT) 1
15 30507 BLACK TORX SCREW WITH FLAT HEAD TYPE F 1/4-20 X 3/4" 4
16 SE75713 ASHTRAY 1
17 30206 ZINC WASHER 5/16"ID X 3/4"OD 1
18 SE70727 GLASS AND MOULDING KIT 1
19 30064 3/16" X 1" CLEVIS PIN 1
20 30059 5/32" ID PUSHNUT 2
21 30060 THREAD-CUTTING SCREW 1/4-20 X 1/2" F HEX STEEL SLOT WASHER C102 ZINC 1
22 30102 1/4'' CAST STEEL AIR CONTROL HANDLE WITH MOUNTING SCREW 1
23 SE70720 AIR CONTROL ROD ASSEMBLY 1
24 AC01298 5"Ø FRESH AIR INTAKE KIT 1
25 PL75120 RIGHT OR LEFT DECORATIVE SIDE PANEL 2
26 30337 SQUARE HEAD SET SCREW 1/2-13 X 1-1/2" 2
27 PL34052 LINER FIXATION BRACKET 3
28 29011 4'' X 9" X 1 1/4" REFRACTORY BRICK HD (AC-SB) 12
29 29020 4 1/2'' X 9'' X 1 1/4'' REFRACTORY BRICK HD 4
30 PL36031 3 5/8" X 9'' X 1 1/4'' REFRACTORY BRICK 1
31 PL70516 SECONDARY AIR TUBE 4
32 21521 1 1/4" x 18 7/8" x 9 1/2" C-CAST BAFFLE 1
33 OA10128 BLACK LARGE FACEPLATE TRIMS (32" X 50") 1
34 OA10122 BLACK FACEPLATE TRIMS (29" X 44") 1
35 OA10117 LARGE FACEPLATE (32" X 50") 1
36 PL70673 FACEPLATE TOP PANEL 30 X 50 1
37 PL70674 FACEPLATE SIDE PANEL 30 X 50 2
