• Explanation of Graphical Symbols
The lightning with arrowhead symbol, within an equilateral triangle, is
intended to alert you to the presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of
nt magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert you to the
presence of important operating and maintenance (servicing) instructions in the
literature accompanying the product.
APPLICABLE FOR USA, CANADA OR WHERE
APPROVED FOR USAGE
CAUTION: TO PREVENT ELECTRIC SHOCK,
MATCH WIDE BLADE PLUG TO WIDE SLOT,
INSERT FULLY.
ATTENTION: POUR EVITER LES CHOCS
ELECTRIQUES, INTRODUIRE LA LAME
LA PLUS LARGE DE LA FICHE DANS LA
BORNE CORRESPONDANTE DE LA PRISE ET
POUSSER JUSQU AU FOND.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
RISQUE DE CHOQUE ÉLECTRIQUE
N'OUVREZ PAS
CAUTION: To reduce the risk of electric shock, do not remove cover (or back).
No user-serviceable parts inside. Refer servicing to
service personnel.
I M POR TA N T SAFET Y INFORM ATIO N
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
s) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding-type plug has
two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not
into your outlet, consult an
electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories
by the manufacturer.
12. Unplug this apparatus during lightning storms or when unused for long periods of time.
13. Refer all servicing to
service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been
dropped.
14. The apparatus shall not be exposed to dripping or splashing and that no objects
with liquids, such as vases, shall be placed on the apparatus.
15. CAUTION: Servicing instructions are for use by
service personnel only. To reduce the risk of electric shock, do not perform any servicing other than that
contained in the operating instructions unless you are
to do so.
16. WARNING: To reduce the risk of
re or electric shock, do not expose this apparatus to rain or moisture.
17. Where an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the OSD Audio SMP200 and is the answer not in the manual?

OSD Audio SMP200 Specifications

Audio Specifications IconAudio Specifications
maximum output power120W/8Ω; 200W/4Ω
total harmonic distortion (THD)1%
frequency response20Hz-160Hz +/-1dB
signal to noise ratio95dB
input sensitivity200mV
crossover frequency35-160Hz
phase adjustment0-180°
General Specifications IconGeneral Specifications
trigger input voltage+12VDC to +24VDC
line voltage range110-120/220-240 VAC
standby power consumption1.8W
Weight and Dimensions IconWeight and Dimensions
dimensions (W x H x D)8.5” x 1.75” x 9.8” (214mm x 250mm x 44mm)
overall length (including knobs/connectors)10.7” (272mm)
weight2.9 lbs (1.32 kg)
