5
1. Seat
2. Locking lever for footrest
(Ottoman position)
3. USB port and holder
4. Lower arm airbag massage unit
5. Hip airbag massage unit
6. Surround sound speaker
7. Upper arm airbag massage unit
8. Backrest pad
9. Headrest pad
Names of parts and functions
10. Pocket for controller
11. Footrest massage unit
12. Backrest cover
13. Casters
14. Power cord and power plug*
15. Main power switch
16. Power inlet
*Power plug and main power switch will vary according
to country
*Product images are for illustrative purposes only and are not drawn to scale.
12
Massage chair
14
13
15
1
4 5
76 8 9
11
10
16
2
3
