Dismounting
7 Dismounting
Disconnect all attached cables. Dismount the e:cue SYMPL Core S from
the rail by pulling the black DIN rail handle and unhitching the
SYMPL Core S. The dismounting is completed.
8 Product specications
Product number AB447060035
Dimensions (W x H x D) 71.5 x 90.5 x 62 mm
0.28 x 0.30 x 0.20 in
(without fastening clip)
Weight 170 g
Power supply input 24 V DC on screw terminal
wire gauge: 0.25 ... 2.5 sqmm
(0.5 sqmm for exible wires with
ferrules)
Power consumption max. 12 W incl. external USB load
Operating temperature 0 … 40 °C / 32 … 104 °F
Storage temperature -10 ... 70 °C / 14 ... 158 °F
Operating / storage humidity 0 … 80%, non-condensing
Protection class IP20
Electrical safety SELV
Housing Self extinguishing blend PC / ABS
UL document E140692
!
Before dismounting, appropriate measures must be taken to
protect the respective components against damage caused
by electrostatic discharge (ESD protection).
