General device description
2 General device description
e:cue SYMPL Nodes are a system of interfaces for e:cue SYMPHOLIGHT
only. They provide various connection types like DMX512, DALI, digital
inputs and outputs etc. SYMPL Nodes always operate in online mode, as a
device interface for SYMPHOLIGHT. All interactions are initiated and
controlled by SYMPHOLIGHT. Connections between servers, Cores and
Nodes are always made with e:net via Ethernet.
e:cue SYMPL Core S is a stand-alone engine for e:cue SYMPHOLIGHT
with SYMPL Nodes as interfaces. It executes SYMPHOLIGHT shows in
small to medium-sized shows and controls all available SYMPL Nodes. As
a user interface it utilizes the Action Pad of SYMPHOLIGHT with all usual
web browsers. The connection between SYMPL Core S, external systems
and the Nodes is a standard Ethernet network. Shows can be transferred
to the SYMPL Core S from a SYMPHOLIGHT server or uploaded from
many sources.
2.1 Delivery content
Delivery content for the e:cue SYMPL Core S (AB447060035):
1. e:cue SYMPL Core S
2. Safety instructions
3. Installation guide (English only)
To operate SYMPL Nodes a SYMPHOLIGHT version 2.0 or
higher is mandatory. Earlier versions do not support the
SYMPL Nodes. SYMPL Nodes are not supported by the
e:cue Lighting Application Suite.
e:cue SYMPL Core S is not hot-pluggable.
