OTICON ACTO FITTING GUIDE
33
Place the locking plate on the Receiver housing and use the
special screwdriver provided in the kit to turn the locking plate
approx. 45 degrees clockwise until it locks into the grooves of
the shell.
Next snap the Receiver cover into the faceplate, covering the
Receiver housing and surrounding the base of the tubing for
reduced visibility.
Removing the Power Mould
To remove the Receiver unit, first remove the cover by very
gently sliding the screwdriver between the tube and the cover
and applying a slight upward pressure.
Using the screwdriver, turn the locking plate counterclockwise
by approx. 45 degrees. You will feel a slight release and then
remove the plate.
Grasp the Receiver unit as illustrated and pull straight out from
the Power Mould.
