oticon Own 2 - Technical Data - IIC

80
About Getting started Daily use Options Tinnitus Warnings More info
IIC
Measured
according to
American
National Standard
ANSI S3.22-2014,
IEC 60118-0:2015
and IEC 60318-
5:2006
Supply voltage:
Zinc-Air
Technical Data
0 dB SPL ref. 20 mPa Own 1 Own 2,3,4,& 5
Peak OSPL90 108 dB SPL 108 dB SPL
HF Average OSPL90 103 dB SPL 103 dB SPL
Peak Full-on Gain 42 dB 43 dB
HF Average Full-on Gain 39 dB 40 dB
Reference Test Gain 27 dB 27 dB
Frequency Range 100-9200 Hz 100-7500 Hz
Total Harmonic Distortion 500 Hz <2 % <2 %
Total Harmonic Distortion 800 Hz <2 % <2 %
Total Harmonic Distortion 1600 Hz <3 % <3 %
Equivalent Input Noise Level (omni) 19 dB SPL 19 dB SPL
Attack Time 5 5
Release Time 29 29
