16
7.3 Adjusting the dipswitches of the 1-channel transmitter and receiver
To make the 1-channel receiver work with the 1-channel transmitter you have to adjust the dipswitches
of both in the same way.
1-channel receiver 1-channel transmitter
The receiver and transmitter always have the same dipswitch settings, when they come from the
manufacturer.
We recommend to adjust the dipswitch always to prevent that a signal from another hinge can give a
false hinge-is-down command.
7.4 Types and type numbers
2-channel remote = SKE2MLV
2-channel receiver = EKE2MLV
1-channel transmitter = SFB1LV
1-channel receiver = EFB1LV
Dipswitches
