2.4 Outputs
Supply output +/-24Vdc 1 4A current limited 22~29V output, for powering the powered sliding
hinge. Through charge-points. (wiring connected to x10
-2,3)
Supply output +/-24Vdc 2 22~29V output for powering the powered folding hinge board.
Max 2A (externally fused) (wiring connected to x11
-1,2)
Logic switched output 1 If the lift has reached an endpoint and has stopped, this output
will be active as long as the lift is operated. (X11-
3,4)
When dipswitch 2 = off, output active on upper and lower endpoint.
When dipswitch 2 = on, output only active on upper endpoint.
(If setting dipswitch 9 is correct)
Logic switched output 2 This will become active when the lift is operated (left/right) (X12-
1,2)
When dipswitch 2 = off, output active only when swivel switch
and armrest-contact are closed and control is operated.
When dipswitch 2 = on, output always active when control is
operated.
LED on armrest 6V/20mA See function of LED in the armrest ( chapter 10.2)
(wiring connected to x2b
-3,4)
Beeper (buzzer) on PCB See function of beeper (chapter 10.3)
1-segment display Shows failure (report) to installer/mechanic
