OTT MF pro - Appendix; Mean-section and Mid-section Methods

Replacement parts
Table 6 Velocity only sensor
Description Item no.
Sensor with 2 m (6.5 ft) cable 1040500595-0N
Sensor with 6.1 m (20 ft) cable 1040500595-1N
Sensor with 12.2 m (40 ft) cable 1040500595-2N
Sensor with 30.5 m (100 ft) cable 1040500595-3N
Table 7 Velocity with depth sensor
Description Item no.
Sensor with 2 m (6.5 ft) cable 1040500595-0D
Sensor with 6.1 m (20 ft) cable 1040500595-1D
Sensor with 12.2 m (40 ft) cable 1040500595-2D
Sensor with 30.5 m (100 ft) cable 1040500595-3D
Table 8 Handheld meter
Description Item no.
English/Metric 1040500195-S
Accessories
Table 9 General accessories
Description Item no.
Adjustable meter mount 10.405.405.9.5
Power supply, 90–264 VAC, 47–63 Hz, 12 V H002782
AC Adapters, 4-plug wall clip set H002781
Carrying case 10.405.401.9.5
Lanyard, double ended loop 10.405.403.9.5
Lithium battery pack 97.820.021.9.5
Thumb screw kit (includes four thumb screws) 10.405.418.9.5
Universal sensor mount 10.405.419.9.5
USB cable 97.120.412.9.5
Appendix
Mean-section and Mid-section methods
The user can select the Mean-section or the Mid-section method for flow calculations. The Mean-
section method divides the cross-section into individual flow segments. Pairs of adjacent verticals are
the limits of the segments. The two edges of the cross-section are given values of 0 for the velocity
and depth. The total flow is the sum of the partial flows of all segments. Figure 15 shows the
definitions and the equation for the Mean-section method.
