Figure 1 Assembled components
1 Portable meter 7 Sensor height lock/release screw (accessory)
2 Sensor height lock/release device 8 20 mm/HERES wading rod adapter (accessory)
3 Top setting wading rod (accessory) 9 20 mm wading rod (accessory)
4 Sensor cable 10 HERES wading rod (accessory)
5 Adjustable mount for portable meter 11 Sensor height lock/release screw
6 Sensor assembly
Sensor overview
Figure 2 shows the main sensor components. Instructions for how to attach the sensor on a standard
or top-setting or HERES or 20 mm wading rod are supplied with the accessory.
English
7
