1.3 Product overview
1
1 Back padding 11 Mobility base (drive unit bracket)
2 Back 12 Caster wheel
3 Seat module 13 Caster wheel splash guard
4 Side panel with armrest and clothing protector 14 Drive motor with brake release
5 Actuator for power back angle adjustment 15 Suspension for caster wheel swing arm
6 Seat frame 16 Caster wheel swing arm
7 Rear lighting 17 Front lighting
8 Drive wheel splash guard 18 Legrest
9 Drive wheel 19 Seat cushion
10 Anti-tipper 20 Control panel
2 Safety instructions
2.1 Explanation of warning symbols
Warning regarding possible serious risks of accident or injury.
Warning regarding possible risks of accident or injury.
Warning regarding possible technical damage.
