Troubleshooting
B-Series Ottobock | 73
Error message;
Error code
Content
Cause Possible measure
Switch Deta-
ched;
1E07
External on/off switch
disconnected from
control panel
e.g. defective cable connection
to control panel
Defective switch or control panel
Check cable connection and
switching function of the external
switch.
Replace control panel.
Switch Deta-
ched;
1E08
External profile/mode
switch disconnected
from control panel
Switch Short;
1E0D
Short circuit on external
on/off switch
Switch Short;
1E0C
Short circuit on external
profile/mode switch
Gone to Sleep
Control unit switches to
sleep mode
Extended inactivity while control
unit is switched on
Switch control unit off/on.
Charging
Battery charger is con-
nected
Battery charger is connected to
charging receptacle
Disconnect battery charger prior
to driving.
JS Static Time-
out
Joystick holding time
exceeded
Excessive joystick deflection
detected (control unit stops
drive system to prevent potential
damage to the motors)
Defective joystick
Switch control unit off/on.
Replace control panel/joystick.
Gyro Disconnec-
ted
Electronic track sta-
biliser (gyro module)
disconnected from
controller
e.g. defective cable connection
to controller
Defective gyro module
Replace gyro module.
Gyro Prf Active
Electronic track stabi-
liser (gyro module) is
activated
Electronic track stabiliser (gyro
module) is disrupted by the
movement of a different means of
transportation (e.g.train, ship) in
standby
Defective gyro module
To move the wheelchair, select
the "No Assist" driving profile for
safety reasons.
Replace gyro module.
5.3 Display of errors/faults (VR2 control unit)
5.3.1 Visual displays (VR2 control unit)
Error messages are displayed via the flashing signals of the "battery capacity" LED display on the control panel.
LED display Meaning Action
Fast flashing The control system detects an error. Interpret the flashing signals (see Seite74),
connect the handheld programming device,
determine the error code (see Seite74) and
take the recommended actions.
Slow flashing The control system does not register an
error trigger, but an error was possibly
triggered before.
INFORMATION: The fewer LEDs are
flashing, the less battery capacity
remains.
Read the diagnostics report from the control sys-
tem, determine the error code (see Seite74)
and
take the recommended actions.
Charge the batteries.
Display continuously
illuminated
The control system does not register an
error trigger, but an error was possibly
triggered before.
Read the diagnostics report from the control sys-
tem, determine the error code (see Seite74)
and
take the recommended actions.
