24
Removing the plug-on side panels
1) Fold back the side panel.
2) Press in the pushbutton (see fig.25).
3) Take the side panel out of the adapter.
Installing the plug-on side panels
1) Insert the side panel in the adapter.
2) Press in the pushbutton and allow the side panel to engage in the adapter (see fig.26).
3) Fold the side panel forward and lock it.
25 26
Adjusting the forearm support height – side panel with height-adjustable forearm support
The height of the forearm support should only be adjusted by qualified personnel.
Adjusting the forearm support height – side panel with height-adjustable forearm support
1) Push the release button (see fig.27, item1).
2) Adjust the height of the forearm support (see fig.27, item2).
27
21Start M2S, Start M2
Use
