11 Technical data
INFORMATION
► Much of the technical data below is given in mm. Please note that product settings – unless otherwise spe
cified – cannot be adjusted in the mm range but only in increments of approx. 0.5cm or 1cm.
► Note that the values achieved during adjustment may deviate from the values specified below. The deviation
can be ±10mm and ±2°.
INFORMATION
► Some of the measurements indicated below are values that were theoretically determined.
► Note that not all adjustment possibilities can be used with all product versions. Furthermore, the adjustment
combinations are limited by the compact frame geometry.
► Technical changes and tolerances are reserved by the manufacturer.
General information
Start M2S, Start M2
Max. load (in kg) 130
Weight [kg]
(for seat width of 430mm)
from 15.3
1)
Transport weights [kg]
(for seat width of 430mm)
Frame: from 10.2
1)
Leg support: approx. 1.4
1)
Drive wheels 24" (pair): approx. 3.6
1)
Seat width [mm] 380/405/430/455/480/505/530
2)
Seat depth [mm] M2: 405/430/455/480/505
2)
M2S: 430
2);3)
(tool-free adjustment to 405/455)
Lower leg length [mm] (without cushion) M2: 350–490; M2S: 420
3)
Max. overall height [mm]
(for rear seat height: 470mm; back support height
430mm; push handle)
940
Turning circle approx. [mm]
(for seat width of 430mm and seat depth of 430mm)
1,435
2)
Maximum permissible inclination [°]/[%] 7/12.3
Min. tyre pressure [bar] 7
4)
1)
The specified weights vary according to the selected options and model.
2)
In accordance with ISO 7176-5, 8.12
3)
Factory setting, additional adjustments possible
4)
Varies according to tyre option; see the marking on the tyre wall.
Additional information
Start M2, Start M2S Minimum Maximum
Total weight M2: 15.3; M2S: 15.2 M2: 15.4; M2S: 15.3
Mass of the heaviest component [kg] 8.7 8.8
Overall length with foot supports [mm] 970 M2S: 1,045; M2:
1,087
Overall width [mm] M2: 540; M2S: 565 690
Length (folded) [mm] 970 M2: 1,087; M2S:
1,045
Width (folded) [mm] 310 ---
Height (folded) [mm] 940 990
Seat bottom angle [°] 0 5
Effective seat depth [mm] 405 M2: 505; M2S: 455
Effective seat width [mm] 380 505
Front seat height [mm] M2: 400
1)
M2: 510
1)
;
M2S: 490
2)
