Otto Bock Start M2S - Appendices; Train Transport Requirements

Start M2, Start M2S Minimum Maximum
Rear seat height [mm] M2: 380 M2: 500;
M2S: 470
2)
Back support angle [°] 2 ---
Back support height [mm] M2: 400 M2: 475;
M2S: 425
2)
Adjustability of the back support [°] 0 30
Distance from leg support to seat [mm] 280 500
Distance from arm support to seat [mm] 200 220
Drive wheel size ["] 22
3)
24
Caster wheel size ["] 5
1)
8
Angle foot support to seat bottom [°] 2 32
Handrim diameter, single handrims [mm] 500 530
Handrim diameter, double handrims [mm] Inner ring: 355
Outer ring: 500
Inner ring: 405
Outer ring: 530
Minimum turning radius [mm] 747
4)
M2: 877
4)
;
M2S: 824
4)
Positioning of the arm support [mm] 240 320
1)
Deviating values for one-handed operation version
2)
Factory setting, additional adjustments possible
3)
22" drive wheels only for M2 Hemi version
4)
In accordance with ISO 7176-5
Environmental conditions
Temperatures and relative humidity
Operating temperature [°C (°F)] -10to+40 (14to104)
Transport and storage temperature [°C (°F)] -10to+40 (14to104)
Relative humidity [%] 45to85
12 Appendices
12.1 Threshold values for wheelchairs transportable by train
INFORMATION
► The products in this series fully satisfy the minimum technical requirements of regulation (EU) No.1300/2014
regarding train accessibility for people with disabilities. However, not all versions can comply with all
threshold values due to different settings.
► With the help of the table that follows, you or the qualified personnel can take measurements and verify wheth
er the specific product in question meets the threshold values.
Feature Threshold value (according to Regulation (EU)
No.1300/2014)
Length [mm]
1)
1,200 (plus 50mm for the feet)
Width [mm]
1)
700 (plus 50mm on each side for the hands when mov
ing)
Smallest wheels ["]
1)
approx. 3 or greater (according to the directive, the
smallest wheel must be able to overcome a gap measur
ing 75mm horizontally and 50mm vertically)
Height [mm]
1)
max. 1,375mm; including a 1.84m large male wheel
chair user (95th percentile)
Turning radius [mm]
1)
1,500
Maximum weight [kg]
1)
200 (for wheelchair and user, including any baggage)
Maximum obstacle height that can be overcome [mm]
1)
50
Ground clearance [mm]
1)
45Start M2S, Start M2
Appendices
