OUMAN EH-800 Installation Instructions

10
OK
8
CONTROLLER SETTINGS
Turn the control knob to go to time and date settings and press OK.
Set the hours and press OK to
confirm. Set the minutes and
press OK to conrm.
Press OK. Select either a time or date and
press OK.
First set the day, then the month and
then the year. Press OK. (the name
of the weekday is automatically up-
dated).
Press ESC to exit from time and date settings.
9
EH-800 setup
Language/Kieli/Språk Suomi >
Time and date setting >
Measur. channels settings >
Heating mode Radiator heating, normal >
Time
19:44
hh:mm
Give the hours;
pp.kk.vvvv
Date
Tu 11.06.2013
Give the day:
Press OK. Select the measurement use (see alternatives,
section 7). Measurement 3 (4) or alarm can be freely labelled.
The uses for measurements 3 and 4 appear on the display.
Press ESC to exit.
Labelling: Use the control knob to select a letter. Press OK to conrm. Press OK for a number of seconds to conrm
the name. Press ESC to delete the letter. Press ESC for a number of seconds to delete the name. If you take a measure-
ment into alarm use, you can select whether the controller sounds an alarm when the switch opens or when it closes.
The default is that the controller gives an alarm when the switch opens. (see user manual p.23).
10
If you do not take additional connections into use (see section 7), go to section 12.
Taking additional connections (measurements 3 and 4) into use using the cord and connecting box
EH-800 setup
Language/Kieli/Språk English >
Time and date setting >
Measur. channels settings >
Heating mode Radiator heating, normal >
Measurements
Measurement 3 TMR Room measurement >
Measurement 4 Not in use >
Measurements
Measurement 3 Not in use >
Measurement 4 Not in use >
The controller has factory settings for normal radiator heating. Floor heating, normal: normal oor heating Floor heat-
ing, damp rooms: select this when the controller only heats tiled oors (when you want a comfortably warm oor and/
or a dry oor in the summer). Radiator heating, steep curve: select this when your house has poor insulation or the ra-
diators do not give off enough heat. The constant temperature controller and concrete oor drying are special appli-
cations of the controller. (additional information about heating modes in the user manual on p. 26). After initialization, the
heating mode selection can be found from the controller at ”Device settings -> H1 Process settings”.
11
Heating mode selection
Using EH-800 as a heating controller
Measur. channels settings >
Heating mode Radiator heating, normal >
Direction on valve Open clockwise >
Start-up with new settings >
Heating mode
Floor heating, damp rooms
Floor heating, normal
Radiator heating, normal
Radiator heating, steep curve
Contant temperature controller
 Concreteoordrying
Kieli/Språk/Language
Suomi
Svenska
English
EH-800 setup
Kieli/Språk/Language Suomi >
Time and date setting >
Measur. channels settings >
Heating mode Radiator heating, normal >
Changing the language:
Press the control knob (=OK), turn the control knob to change the language and press OK.
