19
8
7
6
5
D
C
B
A
B
C
D
E
F
1
2
3
4
5
6
7
8
F
E
A
Date
Pages
Author
Designer
Scale
Document type
Document description
Item
Document code and revision
1/1
Modifier
Page size
1:1
A4
XL740-A-01
Printing color: RAL 9005 Jet Black
Drawing
OUFLEXMINI PRINTED COVER
09.06.2015
MM
--
--
XL740
9 10 11 12 13 14 15 16 17 18 19 20
C NO C NO C NO C NO C NO C NO
1 2 3 4 5 6 7 8
24V ~/+ B2 A2 B1 A1
21
22
32
42
25
62
72
82
29
03
13
23
33
43
53
63
37
83
93
04
41
24
34
44
45
64
74
84
49
05
15
25
53
45
55
65
57
85
95
06
Y1
PWM
Y3
2Y
M5
4Y
M4
M3
M2
M1
M14
51M
M12
31M
M10
M11
M9
M8
M7
M6
Print1)
Print2)
Print3)
66666
1
2 2
5
Detachable strip connectors
(analog outputs and PWM).
Connector labels::
31 0…10 V output (Y4)
32 GND
33 0…10 V output (Y3)
34 GND
35 0…10 V output (Y2)
36 GND
37 0…10 V output (Y1)
38 GND
39 PWM
40 GND
Detachable strip connectors
(passive sensors and
digital inputs).
21 M1
22 GND
23 M2
24 GND
25 M3
26 GND
27 M4
28 GND
29 M5
30 GND
41 M6
42 GND
43 M7
44 GND
45 M8
46 GND
47 M9
48 GND
49 M10
50 GND
3
Detachable strip connectors
(passive sensors, active sensors and
digital inputs).
51 M11
52 GND
53 M12
54 GND
55 M13
56 GND
57 M14
58 GND
59 M15
60 GND
3 3 3 3 3
5 5 5 5 5
3 3 3 3 3 44444
6
Detachable strip connectors
(relays with normally open
contact max 230 Vac, 5 A).
Connector labels::
9 Relay 1 C
10 Relay 1 NO
11 Relay 2 C
12 Relay 2 NO
13 Relay 3 C
14 Relay 3 NO
15 Relay 4 C
16 Relay 4 NO
17 Relay 5 C
18 Relay 5 NO
19 Relay 6 C
20 Relay 6 NO
RS-232 connection
(External display)
RS-232 connection (Oulink,
SMS-modem)
USB-connector
2
Detachable strip connectors
(RS-485-bus connectors)
Connector labels:
3 GND
4 RS-485-bus connection B2
5 RS-485-bus connection A2
6 GND
7 RS-485-bus connection B1
8 RS-485-bus connection A1
1
Detachable strip connectors
(operation voltage).
Connector labels:
1 24 Vac operation voltage output
2 GND
Micro-SD memory card slot
4
Ouflex M structure
